How to Add Audi R8 Transponder with Auro OtoSys IM100/IM600

How to: Audi R8 add transponder with precode and remote with Auro Otosys IM600 (IM100 do the job too).

auro-otosys-im600-audi-r8-1

Key type: 8P like Audi A3



Procedure:

Step 1: Read IMMO data

Read and save immo data

auro-otosys-im600-audi-r8-2

Step 2: Make Dealer Key

auro-otosys-im600-audi-r8-3

Step 3: Learn Key

Step 4: Add Key

Enter from VDO CDC32XX+24C32 A3/TT/R8

auro-otosys-audi-r8-1

auro-otosys-audi-r8-2

Turn ignition off for 5s and then back to ON. press OK within 2s.

auro-otosys-audi-r8-3

Place the dealer key/chip in the IM600 UP400 or IM100 UP200 key programmer

auro-otosys-audi-r8-4

auro-otosys-audi-r8-5

Communicating with the key

During the subseqent communication process, the instument will have a splash screen or a black scree.
This phenomenon is normal.

auro-otosys-audi-r8-7

auro-otosys-audi-r8-6

Later it will auto reset instrument

auro-otosys-audi-r8-8

Add key success.

auro-otosys-audi-r8-9

Test the new key.

Done.
