Program Lexus ES 300 2013 All Keys Lost with VVDI Prog + Tango

How to Program Lexus ES300 year 2103 4-button smart key when all keys lost by using Xhorse VVDI Prog and Tango key programmer.

lexus-es300-tango-vvdi-prog-2

Step 1: Read EEPROM 93C46

Follow wiring diagram to connect ecu IC 93C46 with Xhorse VVDI Prog and eeprom clip adapter.

lexus-es300-tango-vvdi-prog-1

Choose ecu and chip type, read and save eeprom data, i.e lexus2013.bin

lexus-es300-tango-vvdi-prog-3 lexus-es300-tango-vvdi-prog-4

Step 2: Make key with Tango

Open Tango transponder key programmer software

lexus-es300-tango-vvdi-prog-5

Upload eeprom data just read by VVDI Prog

lexus-es300-tango-vvdi-prog-6

lexus-es300-tango-vvdi-prog-7

Select TMS 37200

lexus-es300-tango-vvdi-prog-8

Insert key into Tango key programmer or attached smart key very close to Tango to identify

lexus-es300-tango-vvdi-prog-9

Tango has created the new key data bin file (i.e lexus2013b.bin).
Upload the new file to the immobilizer memory to complete key programming.

lexus-es300-tango-vvdi-prog-10

1st key is programmed

lexus-es300-tango-vvdi-prog-11



Step 3: Write back new key data to programmer

Upload new key data lexus2013b.bin file to vvdi prog

Click on Write

Write key data success

lexus-es300-tango-vvdi-prog-12

Save the new written eeprom data, i.e lexus2013eest.bin





Step 4: Program key success

Open Tango software again

Upload the new eeprom data lexus2013eest.bin

Press Program key icon

Key has been programmed successfully

lexus-es300-tango-vvdi-prog-13
